Full automation
Real "walk-away"operation facilitated by the automatic sample loading, aspiration, dripping, analysis and report
Unique IC card control system
Reduce the difference between strips and make the result more accurate.
High-precision volume dripping system
Ensure that the sample volume on strip pads is accurate and reduce the contamination on the table.
Unique system upgrade function
Use TF card to upgrade and maintain the software to make users simultaneously experience the latest software support.
High speed processor
Each module of the instrument adopts 32 bit arm processor and is connected by CAN bus. It is fast, accurate,has low failure rate.
Online function
The analyzer is connectable to urine sediment analyzer to provide comprehensive solutions with comprehensive report of urine dry chemistry test results, mirror examination results and the physical and chemical indicators.
Main Technical Specifications:
Test Items : URO, BIL, KET, BLD, PRO, NIT, LEU, GLU, SG, pH, VC, MAL, CRE, CAL
Wavelength of Monochromatic Light : 525nm, 610nm, 660nm
Strip pads : Reflectance photometer
Test speed : 240 samples/hour(15 second/strip)
On board sample capacity : 5 racks of 10 tubes (50 samples) / 6 racks of 10 tubes(60 samples)
Sample volume : Minimum volume: 3 ml
Aspiration volume : Less than 1 ml
Data storage capacity : 20000
External output : RS-232
Power supply : AC 100-240V 50/60Hz
Power : 300VA
Environment : Temperature 15°C ~ 35°C, Optimum temperature 20°C ~25°C,Relative humidity ≤75%
Dimensions : 660 x 625 x 581mm (L x W x H)
Weight : 65kg
Printer : Thermal printer
